Built-in Functions
Availability:
Requires
Examples:
Example
Files:
Also See:
Only on devices with built-in LCD Driver Module hardware.
Constants are defined in the devices * .h file.
lcd_load(buffer, 0, 16);
ex_92lcd.c
lcd_symbol(), setup_lcd(), lcd_contrast( ), Internal LCD Overview
lcd_symbol( )
Syntax:
lcd_symbol ( symbol, bX_addr );
Parameters: symbol is a 8 bit or 16 bit constant.
bX_addr is a bit address representing the segment location to be used for bit X of
the specified symbol.
1-16 segments could be specified.
Returns:
Function:
Availability:
Requires
Examples:
undefined
This function loads the bits for the symbol into the segment data registers for the
LCD with each bit address specified. If bit X in symbol is set, the segment at
bX_addr is set, otherwise it is cleared. The bX_addr is a bit address into the LCD
RAM.
Only on devices with built-in LCD Driver Module hardware.
Constants are defined in the devices *.h file.
byte CONST DIGIT_MAP[10] = {0xFC, 0x60, 0xDA, 0xF2, 0x66, 0xB6, 0xBE, 0xE0, 0xFE, 0xE6};
#define DIGIT1
COM1+20, COM1+18, COM2+18, COM3+20, COM2+28, COM1+28, COM2+20, COM3+18
for(i = 0; i <= 9; i++) {
lcd_symbol( DIGIT_MAP[i], DIGIT1 );
delay_ms( 1000 );
}
Example
Files:
Also See:
ex_92lcd.c
setup_lcd(), lcd_load(), lcd_contrast( ), Internal LCD Overview
201
